Zoom the image with the mouse
GetSat
GetSat GS751 - Ruggedized satellite modem
Condition:
New
Availability:
YES
Weight:
3.80 KGS
Width:
30.50
(cm)
Height:
4.50
(cm)
Depth:
30.50
(cm)
Request a quote at Contact@orbitalconnect.com or +1.888.315.9545
GS751
Ruggedized satellite modem
GS751 is the newest member of Get SAT’s family of modem options. Developed with the integration of the CX751 GX Core Module, this next-generation ruggedized satellite router is a multi-core, multi-function modem option for the most demanding users.
GS751 provides an external, IP66 rated modem option for users to access INMARSAT’s Global Xpress® Ka-band network in any weather and environmental conditions.
Pair a GS751 external modem with any one of Get SAT’s Global Xpress® type-approved terminals for the ultimate in worldwide satellite communications (satcom) on the move capabilities.
Key Features
Encryption
An encrypted user data traffic using advanced encryption techniques.
Monitoring
An inside comfortable spectrum analyzer to monitor the signal and Packet capture and ping tools to monitor user data traffic.
Configuration management
An easy configuration saving, switching, importing and exporting.
Remote Modem Control
A capability to easily control the remote modem by a diverse set of commands.
Tech Spec
| NETWORK CONFIGURATION | ||
|---|---|---|
| Network Topology<strong<></strong<> | Star<strong<></strong<> | |
| Downstream | Upstream | |
| DVB-S2 | Adaptive TDMA | |
| Modulation | QPSK, 8PSK, 16APSK, 32APSK | BPSK, QPSK, 8PSK |
| FEC | LDPC, 1/4 - 8/9 | 2D 16-State, 1/2 - 6/7 |
| Max. Info Rate | 1-4 Msps | 128 kssps - 7.5 Msps |
| Max. IP Data Rate | 149.7 Mbps | 19.2 Mbps |
| Spread Spectrum (Max Rate Mcps) | Up to 7.5 Mcps Spreading Factors: 2, 4, 8 |
|
| Maximum downstream and upstream data rates cannot be achieved simultaneously Maximum rates are achieved with optimal configurations |
||
| INTERFACES<strong<></strong<> | ||
| SatCom Interfaces | Tx: Type-SMA, 950-2400 MHz, +5dBm/-35dBm, 50Ω Rx: Type-SMA, 950-2150 MHz, -5dBm (max) composite/ -130+10*log (Sym rate) dBm (min) single carrier, 50Ω Rx Reference Port (Out): Type-SMA, 50Ω |
|
| Data Interfaces | LAN: Dual 10/100/1000 Mbps Ethernet | |
| Security | AES FIPS 140-2 Level 3, Link Encryption (256-bit)**, TRANSEC, X.509 digital certificates authentication, Automatic Key Management |
|
| Protocols Supported | TCP, UDP, ICMP, IGMP, RIPv2, Static Routes, NAT, DHCP, DHCP Helper Local DNS Caching, OpenAMIP, cRTP, and GRE |
|
| Traffic Engineering | Group QoS, QoS (Priority Queuing and CBWFQ), Strict Priority Queuing, Application Based QoS, Minimum CIR, CIR (Static and Dynamic), Rate Limiting |
|
| Other Features | Built-in Automatic Uplink Power, Frequency and Timing Control, Authentication, Antenna Control Interface (OpenAMIP), Supports Multiprotocol Encapsulation (MPE), Low-Speed COTM |
|
| Interface to SAT | Supports Connection to All GetSAT Products one Cable Connection to The Terminal | |
| Mechanical/Environmental<strong<></strong<> | ||
| Size | 30.5 x 30.5 x 4.5 cm (12 x 12 x 1.77”) | |
| Weight | 3.8 Kg (8.4 lb) | |
| Operating Temperature | -40° to +140°F (-40° to +60°C) | |
| Input Voltage | 24-48v DC | |
| Power Consumption | < 20 Watts | |
| Certifications | Built to meet FCC, UL, CE, EU and Canadian Standards RoHS compliant WGS certification pending Meets MIL-STD 810G |
5 customers are viewing this product
Details
GS751
Ruggedized satellite modem
GS751 is the newest member of Get SAT’s family of modem options. Developed with the integration of the CX751 GX Core Module, this next-generation ruggedized satellite router is a multi-core, multi-function modem option for the most demanding users.
GS751 provides an external, IP66 rated modem option for users to access INMARSAT’s Global Xpress® Ka-band network in any weather and environmental conditions.
Pair a GS751 external modem with any one of Get SAT’s Global Xpress® type-approved terminals for the ultimate in worldwide satellite communications (satcom) on the move capabilities.
Key Features
Encryption
An encrypted user data traffic using advanced encryption techniques.
Monitoring
An inside comfortable spectrum analyzer to monitor the signal and Packet capture and ping tools to monitor user data traffic.
Configuration management
An easy configuration saving, switching, importing and exporting.
Remote Modem Control
A capability to easily control the remote modem by a diverse set of commands.
Tech Spec
| NETWORK CONFIGURATION | ||
|---|---|---|
| Network Topology<strong<></strong<> | Star<strong<></strong<> | |
| Downstream | Upstream | |
| DVB-S2 | Adaptive TDMA | |
| Modulation | QPSK, 8PSK, 16APSK, 32APSK | BPSK, QPSK, 8PSK |
| FEC | LDPC, 1/4 - 8/9 | 2D 16-State, 1/2 - 6/7 |
| Max. Info Rate | 1-4 Msps | 128 kssps - 7.5 Msps |
| Max. IP Data Rate | 149.7 Mbps | 19.2 Mbps |
| Spread Spectrum (Max Rate Mcps) | Up to 7.5 Mcps Spreading Factors: 2, 4, 8 |
|
| Maximum downstream and upstream data rates cannot be achieved simultaneously Maximum rates are achieved with optimal configurations |
||
| INTERFACES<strong<></strong<> | ||
| SatCom Interfaces | Tx: Type-SMA, 950-2400 MHz, +5dBm/-35dBm, 50Ω Rx: Type-SMA, 950-2150 MHz, -5dBm (max) composite/ -130+10*log (Sym rate) dBm (min) single carrier, 50Ω Rx Reference Port (Out): Type-SMA, 50Ω |
|
| Data Interfaces | LAN: Dual 10/100/1000 Mbps Ethernet | |
| Security | AES FIPS 140-2 Level 3, Link Encryption (256-bit)**, TRANSEC, X.509 digital certificates authentication, Automatic Key Management |
|
| Protocols Supported | TCP, UDP, ICMP, IGMP, RIPv2, Static Routes, NAT, DHCP, DHCP Helper Local DNS Caching, OpenAMIP, cRTP, and GRE |
|
| Traffic Engineering | Group QoS, QoS (Priority Queuing and CBWFQ), Strict Priority Queuing, Application Based QoS, Minimum CIR, CIR (Static and Dynamic), Rate Limiting |
|
| Other Features | Built-in Automatic Uplink Power, Frequency and Timing Control, Authentication, Antenna Control Interface (OpenAMIP), Supports Multiprotocol Encapsulation (MPE), Low-Speed COTM |
|
| Interface to SAT | Supports Connection to All GetSAT Products one Cable Connection to The Terminal | |
| Mechanical/Environmental<strong<></strong<> | ||
| Size | 30.5 x 30.5 x 4.5 cm (12 x 12 x 1.77”) | |
| Weight | 3.8 Kg (8.4 lb) | |
| Operating Temperature | -40° to +140°F (-40° to +60°C) | |
| Input Voltage | 24-48v DC | |
| Power Consumption | < 20 Watts | |
| Certifications | Built to meet FCC, UL, CE, EU and Canadian Standards RoHS compliant WGS certification pending Meets MIL-STD 810G |
Download
| Download Name | |
| GS751 - Ruggedized satellite modem Data Sheet | |
