ETL Systems
ETL Systems EQUL1P-4524 L-band Passive Equaliser 850–2150 MHz
Product Code:
EQUL1P-4524
Condition:
New
Weight:
1.00 KGS
Width:
8.30
(cm)
Height:
3.20
(cm)
Depth:
1.60
(cm)
Request a quote at Contact@orbitalconnect.com or +1.888.218.9394
The EQUL1P-4524 is a passive L-band equaliser designed to correct signal slope over long coaxial cable runs. With a fixed 4 dB positive slope across the 850–2150 MHz frequency range, it ensures consistent signal levels by offsetting high-frequency losses.
This unit features a 50Ω impedance and is available with SMA, N-Type, or BNC connectors. Its design allows for DC and 10 MHz signal pass-through, making it suitable for systems requiring reference signals or remote powering.
| SKU | Freq. Low2 | Freq. High2 | Slope Positive Typ. (dB) | DC Pass | DC Block | Input Power Rating |
| EQUL1P-4524-B5B5 | 850MHz | 2150MHz | 4 | All Ports | None | +37 dBm (5W) |
| EQUL1P-4524-N5N5 | 850MHz | 2150MHz | 4 | All Ports | None | +37 dBm (5W) |
| EQUL1P-4524-S5S5 | 850MHz | 2150MHz | 4 | All Ports | None | +37 dBm (5W) |
5 customers are viewing this product
Details
The EQUL1P-4524 is a passive L-band equaliser designed to correct signal slope over long coaxial cable runs. With a fixed 4 dB positive slope across the 850–2150 MHz frequency range, it ensures consistent signal levels by offsetting high-frequency losses.
This unit features a 50Ω impedance and is available with SMA, N-Type, or BNC connectors. Its design allows for DC and 10 MHz signal pass-through, making it suitable for systems requiring reference signals or remote powering.
| SKU | Freq. Low2 | Freq. High2 | Slope Positive Typ. (dB) | DC Pass | DC Block | Input Power Rating |
| EQUL1P-4524-B5B5 | 850MHz | 2150MHz | 4 | All Ports | None | +37 dBm (5W) |
| EQUL1P-4524-N5N5 | 850MHz | 2150MHz | 4 | All Ports | None | +37 dBm (5W) |
| EQUL1P-4524-S5S5 | 850MHz | 2150MHz | 4 | All Ports | None | +37 dBm (5W) |
