CPI
CPI HD-30T Series Dual Axis Ground Data Terminal
Product Code:
HD-30T
Condition:
New
Weight:
1,031.00 KGS
Request a quote at Contact@orbitalconnect.com or +1.888.218.9394
The HD-30T series tactical Ground Data Terminal was designed for quick deployment in harsh environments. The HD-30T can be deployed in less than 15 minutes with no hand tools required. A standard 1.2 meter segmented parabolic reflector provides high antenna gain and a quickly deployable 1.0 meter FLAPS™ Reflector is also an option for the HD-30T. The system’s Antenna Control Unit, Servo Amplifiers and Power Supplies are self-contained in the pedestal base. Operator interfaces for command and control are provided through an ethernet UDP/IP port and a serial control interface is optional.
Features:
- Available in X, Ku, Dual X & Ku Band
- 1.2 meter (4 ft.) Reflector
- Full Duplex-CDL Band
- Cassegrain Configuration
- Auto Tracking Feed Assembly
- Lightweight Pedestal Assembly
- Three (3) Transit Cases
- MIL-STD-810F Compliant
- MIL-STD-461E Compliant
- UDP/IP Command and Control Interface
- CPI Malibu FLAPS™ 1.0 meter Reflector (Optional)
- 18° Beam Acquisition-Aid Antenna (Optional)
- Serial Control Interface (Optional)
5 customers are viewing this product
Details
The HD-30T series tactical Ground Data Terminal was designed for quick deployment in harsh environments. The HD-30T can be deployed in less than 15 minutes with no hand tools required. A standard 1.2 meter segmented parabolic reflector provides high antenna gain and a quickly deployable 1.0 meter FLAPS™ Reflector is also an option for the HD-30T. The system’s Antenna Control Unit, Servo Amplifiers and Power Supplies are self-contained in the pedestal base. Operator interfaces for command and control are provided through an ethernet UDP/IP port and a serial control interface is optional.
Features:
- Available in X, Ku, Dual X & Ku Band
- 1.2 meter (4 ft.) Reflector
- Full Duplex-CDL Band
- Cassegrain Configuration
- Auto Tracking Feed Assembly
- Lightweight Pedestal Assembly
- Three (3) Transit Cases
- MIL-STD-810F Compliant
- MIL-STD-461E Compliant
- UDP/IP Command and Control Interface
- CPI Malibu FLAPS™ 1.0 meter Reflector (Optional)
- 18° Beam Acquisition-Aid Antenna (Optional)
- Serial Control Interface (Optional)
