Baird WL2-23 Wall Mount

WL2-23 Offset Wall Mount

Achieve superior performance with the Baird WL2-23 Offset Wall Mount Kit. This heavy-duty offset wall mount is specifically engineered for larger antennas up to 1.8m, cameras, monitoring equipment, wireless antennas, microwave antennas, solar applications, and more, offering a 23" offset from the wall and customizable mast heights of 3', 5', or 8' from the base, ensuring optimal positioning for reliable signal reception, surveillance, data collection, or energy harvesting.

Features

• Durable Construction: Crafted from hot dip galvanized steel, this heavy-duty offset wall mount withstands harsh weather conditions, providing a sturdy and long-lasting platform for your larger antennas, cameras, or monitoring equipment.

• Ample Offset: With a 23" offset from the wall, this wall mount for antennas and cameras allows you to position your devices for maximum efficiency, avoiding obstructions from structures, eaves, or soffits.

• Adjustable Height Options: Choose from taller mast heights of 3', 5', or 8' to elevate your equipment high enough to clear potential barriers and enhance performance.

• Versatile Mast Compatibility: Supports larger mast diameters ranging from 2.37" O.D. to 6.62" O.D., making it ideal for a wide variety of heavy-duty antenna mounts, camera mounts, and monitoring equipment setups.

• Easy Installation: Includes a user-friendly installation guide and access to instructional videos, making setup straightforward even for beginners.

• 10-Year Warranty: All Baird mounts, including the WL2-23 Offset Wall Mount, are designed and manufactured in the USA and backed by a 10-year product warranty.

• Broad Compatibility: Works seamlessly with larger antennas up to 1.8m, cameras, monitoring equipment, wireless antennas, microwave antennas, solar modules up to 30 sq ft, and similar devices. Optional adapters can be added for enhanced customization.

Specifications

• Offset from Wall: 23"

• Mast Height Options: 3', 5', or 8' from the base of the mount

• Mast Diameter Compatibility: 2.37" O.D. to 6.62" O.D.

• Weight: 163 lbs. to 242 lbs. depending on mast size

• Warranty: 10 years

• Manufacturing: Designed and manufactured in the USA

What's Included

• Baird WL2-23 Offset Wall Mount: Precision-engineered to securely hold your larger antennas, cameras, or monitoring equipment at the ideal offset and height for heavy-duty applications.

• All Necessary Hardware: Provided for a hassle-free and secure installation.  Hardware includes thru-wall mounting kit and back plates.

The Baird WL2-23 Offset Wall Mount is your go-to solution for professional-grade, heavy-duty wall mounting of larger antennas, cameras, and monitoring equipment. Ensure seamless integration by selecting compatible adapters as needed for your setup.
