14510 SeriesThe model 14510 diplexer is used to combine the downlink and uplink bands to allow for simultaneous transmit and receive operation. Each portion of the diplexer has integrated bandpass filters, matched for optimal system performance. By...

This TX/RX diplexer incorporates highly-selective bandpass filter components to achieve outstanding isolation between uplink & downlink feeds in the wider, super-extended Ku-band.• Compact Size - Ideal for use in confined spaces.• Also...

Utilizing high “Q” bandpass filter components to isolate the transmit and receive feeds, this diplexer is compatible with most standard, extended and super-extended Ku-band applications. • Alternate flange configurations are available...

Used for Ku-(mid) band transmit applications, this filter rejects the receive band and virtually all other undesired signals operating below the transmit band.• Ideal for YAHSAT and other Ku-(mid)band Receive Applications• Multi-Purpose...

This transmit filter prevents the LO (local oscillator), receive band and other lower band signals from interfering with uplink transmissions.• Multi-Purpose Rejection – Eliminates the need for a separate RRF• Alternate Flange...

This pre-amplifier stage transmit filter prevents the receive band, LO (local oscillator) and other lower band signals from interfering with uplink transmissions.• Multi-Purpose Rejection – Eliminates the need for a separate RRF...

This filter isolates transmissions in this frequency band from other sources of communication operating below this band. Specification Details Passband 17.3 – 18.3 GHz Passband Loss 0.5 dB Max; 0.25 dB Typ Passband VSWR 1.25:1...

This compact transmit filter is designed to suppress the 2nd harmonic frequency range of the Ku-Band. Specification Details Passband 13.75 - 14.50 GHz Insertion Loss 0.25 dB Typ VSWR 1.2:1 Max Reject Band 27.5 - 29.0 GHz Rejection 50 dB Min,...

This uplink filter provides isolation from the downlink band of 11.7-12.2 GHz. Specification Details Passband 14.0 - 14.5 GHz Insertion Loss 0.5 dB Max VSWR 1.25:1 Max Reject Bands 10.55 - 10.68 GHz   11.7 - 12.2 GHz Rejection 50 dB...

This filter was designed specifically to reject the Ku-(mid/high) receive band with minimal effect on the Ku-(mid/high) transmit band.• Ideal for Higher Power Transmit Applications.• Alternate Flange Configurations are Available Upon...

This low loss uplink filter provides full band downlink suppression in a compact, yet robust package. Specification Details Passband 13.75 - 14.50 GHz Insertion Loss 0.25 dB Typ VSWR 1.20:1 Max Reject Band 10.70 - 12.75 GHz Rejection 70 dB...
