Norsat International Inc.
Norsat OPT110BX OPTIVIA Starlight Night Vision Gimbal
Product Code:
OPT110BX
Condition:
New
Availability:
10 - 12 Weeks
Weight:
0.69 KGS
Width:
11.00
(cm)
Height:
17.00
(cm)
Depth:
10.96
(cm)
$10,700.00
| KEY SPECIFICATIONS | |
| Recording Time | ≥60 min ≥ Small drone flight time |
| Stabilization Accuracy Horizontal Jitter Angle | ±0.03° |
| Stabilization Accuracy Pitch Jitter Angle | ±0.02° |
| Stabilization Accuracy Roll Jitter Angle | ±0.02° |
| Standard Preinstalled Components | 4K Zoom Camera |
| RF SPECIFICATIONS | |
| Visible Light Detection Detection Tracking Target Size | 4m × 6m |
| Visible Light Detection Maximum Relative Humidity | 70% |
| Visible Light Detection Minimum Visibility | ≥23 km |
| Visible Light Detection Range | ≥8km |
| Visible Light Fov Diagonal | WIDE 66.6º ± 5% TELE 4.0º ± 5% |
| Visible Light Fov Horizontal | WIDE 59.6º ± 5% TELE 3.5º ± 5% |
| Visible Light Fov Vertical | WIDE 35.7º ± 5% TELE 2.0º ± 5% |
| Visible Light Identification Range | ≥5km |
| Visible Light Minimum Identifiable Target Size | 32×32 pixels |
| Visible Light Resolution | 4K, 1080P |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | 6.72W |
| Power Supply | DC 12V - 26.2V (3S -6S) |
| INTERFACE SPECIFICATIONS | |
| Control Method | IP, SBUS or Uart command control |
| External Interface Communication Interface | TTL |
| External Interface Video Interface | IP Network (4K/1080P), Local TF Card Storage for Video Streams |
| ENVIRONMENTAL SPECIFICATIONS | |
| Temperature Operational | -10°C to +55°C (20% - 80% RH) |
| Temperature Storage | -20°C to +60°C (20% to 95% RH) |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 170 mm |
| Product Length | 109.6 mm |
| Product Weight | 0.69 kg |
| Product Width | 110 mm |
| Roll Angle Elevation | -45° to +45° |
| Rotation Range Azimuth | -280° to +280° |
| Rotation Range Elevation | -30° to +120° |
| Volume | 109.6 × 110 × 170 mm |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | EAR99 |
| Harmonized System Code | 8525893900 |
| Unit Package Dimensions | 300 x 240 x 300 mm |
| Unit Package Weight | 6 kg |
| Warranty | 1 |
