Norsat International Inc.
Norsat BT-1198 Bias Tee BT-1100 Series
Product Code:
BT-1198
Condition:
New
Availability:
4 - 6 Weeks
Weight:
0.17 KGS
Width:
5.50
(cm)
Height:
2.50
(cm)
Depth:
10.50
(cm)
$541.00
| KEY SPECIFICATIONS | |
| Band | L-Band |
| Pass Band | 950 - 2150 MHz |
| RF SPECIFICATIONS | |
| 10Mhz Pass Band | 10 - 100 MHz |
| Input VSWR | 2.0 : 1 max. |
| Insertion Loss Max | 1 dB |
| Output VSWR | 2.0 : 1 max. |
| INTERFACE SPECIFICATIONS | |
| 10Mhz Injection | BNC (Female) |
| DC Connector | TNC (Female) |
| Output Connector | N (Female) - 50 Ohm |
| RF Input Connector | N (Female) - 50 Ohm |
| ENVIRONMENTAL SPECIFICATIONS | |
| IP Rating | IP 66 |
| Temperature Operational | -30°C to +50°C |
| Temperature Storage | -40 to +70˚C |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 25 mm |
| Product Length | 105 mm |
| Product Weight | 0.17 kg |
| Product Width | 55 mm |
| ADDITIONAL INFORMATION | |
| Aluminium Content | 0.085 kg |
| Aluminium COO | CN |
| Aluminium Total Value | $ 0.2125 |
| Country Of Origin | Made in Canada |
| ECCN Number | EAR99 |
| Ex Works | Richmond, BC, Canada |
| Harmonized System Code | 8517690000 |
| Unit Package Dimensions | 105 x 55 x 25 mm |
| Unit Package Height | 25 mm |
| Unit Package Length | 105 mm |
| Unit Package Width | 55 mm |
| Warranty | 3 years |
5 customers are viewing this product
Details
| KEY SPECIFICATIONS | |
| Band | L-Band |
| Pass Band | 950 - 2150 MHz |
| RF SPECIFICATIONS | |
| 10Mhz Pass Band | 10 - 100 MHz |
| Input VSWR | 2.0 : 1 max. |
| Insertion Loss Max | 1 dB |
| Output VSWR | 2.0 : 1 max. |
| INTERFACE SPECIFICATIONS | |
| 10Mhz Injection | BNC (Female) |
| DC Connector | TNC (Female) |
| Output Connector | N (Female) - 50 Ohm |
| RF Input Connector | N (Female) - 50 Ohm |
| ENVIRONMENTAL SPECIFICATIONS | |
| IP Rating | IP 66 |
| Temperature Operational | -30°C to +50°C |
| Temperature Storage | -40 to +70˚C |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 25 mm |
| Product Length | 105 mm |
| Product Weight | 0.17 kg |
| Product Width | 55 mm |
| ADDITIONAL INFORMATION | |
| Aluminium Content | 0.085 kg |
| Aluminium COO | CN |
| Aluminium Total Value | $ 0.2125 |
| Country Of Origin | Made in Canada |
| ECCN Number | EAR99 |
| Ex Works | Richmond, BC, Canada |
| Harmonized System Code | 8517690000 |
| Unit Package Dimensions | 105 x 55 x 25 mm |
| Unit Package Height | 25 mm |
| Unit Package Length | 105 mm |
| Unit Package Width | 55 mm |
| Warranty | 3 years |
Download
| Download Name | |
| Norsat Bias Tee 1100 Series Data Sheet | |
