Norsat International Inc.

Norsat PD4BGS RF Power Divider

Name: Norsat PD4BGS RF Power Divider
Brand: Norsat International Inc.
SKU: PD4BGS
Price: 2500 USD
Availability: InStock

No reviews yet

Product Code: PD4BGS

Condition: New

Availability: 10 - 12 Weeks

Weight: 0.00 KGS

Width: 7.11 (cm)

Height: 1.27 (cm)

Depth: 15.85 (cm)

$2,500.00

KEY SPECIFICATIONS
Bandwith	26 GHz
Frequency	0.5 - 26.5 GHz
Noise Figure	N/A
RF SPECIFICATIONS
Gain	N/A
Gain Ripple	N/A
Input VSWR	1.67:1 max.
Insertion Loss	2.3 dB max (500-8000MHz) 3.9 dB max (8000-18000MHz) 5.1 dB max (18000-26500MHz)
Isolation	12 db min (500-1500MHz), 16 db min (1500-18000MHz), 12 dB min (18000-26500MHz)
Ripple	N/A
ELECTRICAL SPECIFICATIONS
Amplitude Balance	0.5 dB max (500-8000Mhz), 0.8 dB max (8000-18000MHz), 1.1 dB max (18000-26500MHz)
Coupling	6 dB nom.
Impedance	50 ohms
Power Handling Avg	10 W max.
INTERFACE SPECIFICATIONS
Connectors Type	SMA-F
ENVIRONMENTAL SPECIFICATIONS
Indoor Status	Yes
PHYSICAL SPECIFICATIONS
Product Height	12.7 mm
Product Length	158.5 mm
Product Width	71.1 mm
ADDITIONAL INFORMATION
ECCN Number	EAR99
Harmonized System Code	8548000000
Unit Packaging Weight	316 g
