Norsat International Inc.
Norsat PD2CGS RF Power Divider
Product Code:
PD2CGS
Condition:
New
Availability:
10 - 12 Weeks
Weight:
0.00 KGS
Width:
2.64
(cm)
Height:
1.27
(cm)
Depth:
14.94
(cm)
$2,400.00
| KEY SPECIFICATIONS | |
| Bandwith | 26 GHz |
| Frequency | 0.5 - 26.5 GHz |
| Noise Figure | N/A |
| RF SPECIFICATIONS | |
| Gain | N/A |
| Gain Ripple | N/A |
| Input VSWR | 1.67:1 max. |
| Insertion Loss | 2.3 dB max. |
| Isolation | 14 dB min (500-1000MHz) 16 dB min (1000-18000MHz) 14 dB min (18000-26500MHz) |
| Ripple | N/A |
| ELECTRICAL SPECIFICATIONS | |
| Amplitude Balance | 0.60 dB max |
| Coupling | 3 dB nom. |
| Impedance | 50 ohms |
| Power Handling Avg | 10 W max. |
| INTERFACE SPECIFICATIONS | |
| Connectors Type | SMA-F |
| ENVIRONMENTAL SPECIFICATIONS | |
| Indoor Status | Yes |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 12.7 mm |
| Product Length | 149.4 mm |
| Product Width | 26.4 mm |
| ADDITIONAL INFORMATION | |
| ECCN Number | EAR99 |
| Harmonized System Code | 8548000000 |
| Unit Packaging Weight | 141g |
