Norsat International Inc.

Norsat RO100KUE040 Rover 1.0 m Ku-Band Manual Acquire Flyaway Antenna

No reviews yet
Product Code: RO100KUE040
Condition: New
Availability: YES
Weight: 32.00 KGS
Width: 170.00 (cm)
Height: 124.00 (cm)
Depth: 98.00 (cm)
Norsat RO100KUE040 Rover 1.0 m Ku-Band Manual Acquire Flyaway Antenna Data Sheet

Request a quote at Contact@orbitalconnect.com or +1.888.315.9545

The ROVER™ is an ultra-lightweight fly-away satellite terminal with unsurpassed reliability, advanced assisted-acquire technology, and a flexible deployment platform. Available in both 1.0 and 1.2 m antenna sizes, the ROVER’s components can be tightly integrated for rapid deployment or separated into indoor and outdoor units for safe operation in dangerous terrain or situations. With IATA compliant packaging and a tool-free assembly process, the ROVER is easy to transport and operate, with military grade durability you can rely on wherever your mission takes you.


KEY SPECIFICATIONS
Product Family ROVER
Band Ku-Band
Reflector Diameter 1.0 m
Acquisition & Tracking Manual
Transmit Frequency Ku-Band: 13.75 - 14.50 GHz
Receive Frequency Ku-Band: 10.95 - 12.75 GHz

ANTENNA SPECIFICATIONS
Polarization Linear Cross-Pol
Feed Configuration 2-port circular
Cross-Polarization Isolation >35 .0 dB within 1 dB contour
Axial Ratio n/a
Elevation Range 5° to 85°, Manual with fine adjust
Azimuth Range +/- 300°, Manual with fine adjust
Primary Antenna Power AC 110/220 VAC (50/60 Hz )
Standard BUC Options 4W, 8W, 16W, 20W, 40W, 80W

RF SPECIFICATIONS
Movement Platform Elevation over Azimuth
G/T 19.5 dB/K
EIRP 56.1 dBW
Tx Gain >41.5 dBi
Rx Gain >40.0 dBi
Output Power( P1dB) 7 dBm
Max SSG Variation +/- 1 dB per 54 MHz
Spectral Regrowth -26 dBc
Reference Signal Frequency 0 +/- 5 dBm @ 10 MHz
Phase Noise @ 1KHz offset -75 dBc/Hz
Phase Noise @ 10KHz offset -80 dBc/Hz
Phase Noise @ 100KHz offset -95 dBc/Hz

ENVIRONMENTAL SPECIFICATIONS
Temperature - Operational -30°C to +55 °C, meets MIL-STD-810G
Rainfall - Operational 15 mm/h, meets MIL-STD-810G
Rainfall - Survival 30 mm/h, meets MIL-STD-810G
Windspeed - Operational 60 km/h
Windspeed - Survival 100 km/h
Humidity 5-95 % non-condensing, meets MIL-STD-810G
Salt Mist Meets MIL-STD-810G
Vibration - Operational Meets MIL-STD-810G
Vibration - Loose Cargo Meets MIL-STD-810G
Vibration - Random Meets MIL-STD-810G
Shock Meets MIL-STD-810G

PHYSICAL SPECIFICATIONS
IATA Cases available Optional
Number of cases 2 standard, 3 IATA
