Microwave Filter Company 18923 VHF/UHF LMR Harmonic Reject Filter
Product Code:
18923
Condition:
New
Weight:
1.00 KGS
Width:
8.90
(cm)
Height:
3.80
(cm)
Depth:
5.10
(cm)
Request a quote at Contact@orbitalconnect.com or +1.888.218.9394
This filter prevents VHF & UHF land mobile radio transmitter harmonic emissions from interfering with wireless services operating between (698 - 2000) MHz.
Features:
- Compact Size for Easy Installation
Applications:
- Prevent Interference to Collocated or Nearby Wireless Services (e.g. – 700 MHz Band, GSM 850, GSM 1900, etc.)
| Product Specifications | |
| Passband | 150 - 465 MHz |
| Passband Loss | 1 dB Approx |
| Passband VSWR (Max) | 1.5:1 |
| Power Rating (CW) | 100 Watts Max |
| Rejection | 80 dB Min from 698 - 2000 MHz |
| Impedance | 50 ohms |
| Connectors | N-Female |
| Dimensions | 89mm x 51mm x 38mm |
5 customers are viewing this product
Details
This filter prevents VHF & UHF land mobile radio transmitter harmonic emissions from interfering with wireless services operating between (698 - 2000) MHz.
Features:
- Compact Size for Easy Installation
Applications:
- Prevent Interference to Collocated or Nearby Wireless Services (e.g. – 700 MHz Band, GSM 850, GSM 1900, etc.)
| Product Specifications | |
| Passband | 150 - 465 MHz |
| Passband Loss | 1 dB Approx |
| Passband VSWR (Max) | 1.5:1 |
| Power Rating (CW) | 100 Watts Max |
| Rejection | 80 dB Min from 698 - 2000 MHz |
| Impedance | 50 ohms |
| Connectors | N-Female |
| Dimensions | 89mm x 51mm x 38mm |
