Microwave Filter Company 18475 Mobile Radio (450-470 MHz) Bandpass Filter
Product Code:
18475
Condition:
New
Weight:
1.00 KGS
Width:
6.00
(cm)
Height:
1.90
(cm)
Depth:
2.50
(cm)
Request a quote at Contact@orbitalconnect.com or +1.888.218.9394
This filter isolates the (450-470 MHz) mobile radio band from potential interference from nearby FM signals (88-108 MHz) and/or nearby 700 MHz band signals.
| Product Specifications | |
| Passband | 450 - 470 MHz |
| Passband Insertion Loss | 1.5 dB Typ 2 dB Max |
| Passband VSWR (Max) | 1.5:1 |
| Rejection | 80 dB Min from 88 - 108 MHz, 40 dB Approx @ 720 MHz |
| Impedance | 50 ohms |
| Connectors | N-Female |
| Operating Temperature Range | +40°F to +100°F |
| Dimensions | 60mm x 25mm x 19mm |
5 customers are viewing this product
Details
This filter isolates the (450-470 MHz) mobile radio band from potential interference from nearby FM signals (88-108 MHz) and/or nearby 700 MHz band signals.
| Product Specifications | |
| Passband | 450 - 470 MHz |
| Passband Insertion Loss | 1.5 dB Typ 2 dB Max |
| Passband VSWR (Max) | 1.5:1 |
| Rejection | 80 dB Min from 88 - 108 MHz, 40 dB Approx @ 720 MHz |
| Impedance | 50 ohms |
| Connectors | N-Female |
| Operating Temperature Range | +40°F to +100°F |
| Dimensions | 60mm x 25mm x 19mm |
