Norsat International Inc.
Norsat Standard C-Band BPF-C-7 Filter
Product Code:
BPF-C-7
Condition:
New
Availability:
YES
Weight:
0.75 KGS
Width:
12.00
(cm)
Height:
10.00
(cm)
Depth:
7.00
(cm)
$532.00
Norsat’s band pass filters reject terrestrial interference in C-Band and can be easily installed between the feed and an LNB. It is suitable for use with Norsat’s existing C-Band LNBs and is environmentally sealed and moisture resistant (IP66). BPF / BPF-C Series.
|
KEY SPECIFICATIONS |
|
|
Band |
C-Band |
|
Input Frequency Band 1 |
C-Band: 4.10 - 4.20 GHz |
|
RF SPECIFICATIONS |
|
|
Output VSWR |
1.4 : 1 |
|
INTERFACE SPECIFICATIONS |
|
|
RF Input Connector |
CPR 229G waveguide grooved |
|
RF Output Connector |
CPR-229F |
|
PHYSICAL SPECIFICATIONS |
|
|
Dimensions (LxWxH) |
120 x 100 x 70 mm |
5 customers are viewing this product
Details
Norsat’s band pass filters reject terrestrial interference in C-Band and can be easily installed between the feed and an LNB. It is suitable for use with Norsat’s existing C-Band LNBs and is environmentally sealed and moisture resistant (IP66). BPF / BPF-C Series.
|
KEY SPECIFICATIONS |
|
|
Band |
C-Band |
|
Input Frequency Band 1 |
C-Band: 4.10 - 4.20 GHz |
|
RF SPECIFICATIONS |
|
|
Output VSWR |
1.4 : 1 |
|
INTERFACE SPECIFICATIONS |
|
|
RF Input Connector |
CPR 229G waveguide grooved |
|
RF Output Connector |
CPR-229F |
|
PHYSICAL SPECIFICATIONS |
|
|
Dimensions (LxWxH) |
120 x 100 x 70 mm |
Download
| Download Name | |
| Norsat Standard C-Band BPF-C-1 Datasheet | |
