Norsat International Inc.
Norsat LNAC10SP Single-Band C-Band LNA - LNA Series
Product Code:
LNAC10SP
Condition:
New
Weight:
0.63 KGS
Width:
16.45
(cm)
Height:
7.00
(cm)
Depth:
9.88
(cm)
$2,380.00
Norsat Single-Band C-Band LNA - LNA Series
| KEY SPECIFICATIONS | |
| band | C-Band |
| input frequency band 1 | 4.50 - 4.80 GHz |
| required current | 200 mA |
| RF SPECIFICATIONS | |
| conversion gain | 50 dB min., 60 dB typ., 65 dB max. |
| Gain Flatness | 4 dB p-p |
| gain ripple (at per 36MHz) | 1 dB p-p |
| input VSWR | 2.2 : 1 |
| output P1dB | + 5 dBm |
| output VSWR | 2.2 : 1 |
| ELECTRICAL SPECIFICATIONS | |
| power connector | MS3112E10-6P |
| power supply | 12-24 VDC |
| INTERFACE SPECIFICATIONS | |
| input W/G flange | CPR 229G |
| ENVIRONMENTAL SPECIFICATIONS | |
| noise temperature | 30'K |
| temperature operational | -40 to +60°C |
| Waterproofing | IP 67 |
| Weight | 630 g |
| PHYSICAL SPECIFICATIONS | |
| dimensions (LxWxH) | 98.8 x 70.0 x 164.5 mm |
5 customers are viewing this product
Details
Norsat Single-Band C-Band LNA - LNA Series
| KEY SPECIFICATIONS | |
| band | C-Band |
| input frequency band 1 | 4.50 - 4.80 GHz |
| required current | 200 mA |
| RF SPECIFICATIONS | |
| conversion gain | 50 dB min., 60 dB typ., 65 dB max. |
| Gain Flatness | 4 dB p-p |
| gain ripple (at per 36MHz) | 1 dB p-p |
| input VSWR | 2.2 : 1 |
| output P1dB | + 5 dBm |
| output VSWR | 2.2 : 1 |
| ELECTRICAL SPECIFICATIONS | |
| power connector | MS3112E10-6P |
| power supply | 12-24 VDC |
| INTERFACE SPECIFICATIONS | |
| input W/G flange | CPR 229G |
| ENVIRONMENTAL SPECIFICATIONS | |
| noise temperature | 30'K |
| temperature operational | -40 to +60°C |
| Waterproofing | IP 67 |
| Weight | 630 g |
| PHYSICAL SPECIFICATIONS | |
| dimensions (LxWxH) | 98.8 x 70.0 x 164.5 mm |
