Norsat International Inc.

Norsat 1000 Series HS1057CN Ku-Band Single-Band LNB

No reviews yet
Product Code: HS1057CN
Availability: YES
Weight: 0.30 KGS
Width: 4.20 (cm)
Height: 4.20 (cm)
Depth: 11.10 (cm)
$462.00

Norsat’s Low Noise Blocks (LNBs) provide signal reception for satellite communications around the world. We offer premium performance and reliability in the smallest form factor possible. All of our standard Ku-Band LNBs are backed by a 3 year warranty and nearly forty years of experience as the industry’s leading provider of high performance LNBs. KU-BAND PLL LNB; 10.95-11.70GHZ; LO: +/-5KHZ; NF: 0.7DB; N-CONN



KEY SPECIFICATIONS
Product Family 1000 Series
Band Ku-Band
LO Type PLL
# of onboard LOs Single-band
LO Stability +/- 5 kHz
Noise Figure 0.7 dB
Input Frequency - Band 1 Ku-Band: 10.95 - 11.70 GHz
Output Frequency 1 L-Band: 950 - 1700 MHz

RF SPECIFICATIONS
LO Frequency 1 10.00 GHz
Phase Noise @ 1KHz offset -70 dBc/Hz
Phase Noise @ 10KHz offset -75 dBc/Hz
Phase Noise @ 100KHz offset -90 dBc/Hz
Conversion Gain 60 dB typ
Gain Variation over operating band ≤ 5 dB p-p
Input VSWR 2.5 : 1
Output VSWR 2.2 : 1
Output P1dB compression point 4 dBm

ELECTRICAL SPECIFICATIONS
Power Requirements 15 - 24 V
Current Drain 300 mA

INTERFACE SPECIFICATIONS
RF Input Connector WR-75 waveguide grooved
RF Output Connector N-50 Ohm

M & C SPECIFICATIONS
LED Indicators None

ENVIRONMENTAL SPECIFICATIONS
Temperature - Operational -40 to +60°C
Temperature - Storage -40 to +60°C

PHYSICAL SPECIFICATIONS
Dimensions (L x W x H) 110 x 42 x 42 mm
Weight 300 g
