Norsat International Inc.

Norsat COU30A Directional Coupler

Name: Norsat COU30A Directional Coupler
Brand: Norsat International Inc.
SKU: COU30A
Price: 900 USD
Availability: InStock

No reviews yet

Product Code: COU30A

Condition: New

Availability: 10 - 12 Weeks

Weight: 0.00 KGS

Width: 1.85 (cm)

Height: 1.27 (cm)

Depth: 15.24 (cm)

$900.00

KEY SPECIFICATIONS
Bandwith	7.7 GHz
Frequency	0.3 - 8 GHz
Noise Figure	N/A
RF SPECIFICATIONS
Gain	N/A
Gain Ripple	N/A
Input VSWR	1.38:1 max (300-6000MHz) 1.43:1 max (6000-8000MHz)
Insertion Loss	1.0 dB max.
Isolation	55 dB min (300-8000MHz)
Ripple	N/A
ELECTRICAL SPECIFICATIONS
Coupling	30 ± 1.2 dB
Impedance	50 ohms
Power Handling Avg	50 W max.
INTERFACE SPECIFICATIONS
Connectors Type	SMA-F
ENVIRONMENTAL SPECIFICATIONS
Indoor Status	Yes
PHYSICAL SPECIFICATIONS
Product Height	12.7 mm
Product Length	152.4 mm
Product Width	18.5 mm
ADDITIONAL INFORMATION
ECCN Number	EAR99
Harmonized System Code	8525503035
Unit Packaging Weight	86g
