Norsat International Inc.
Norsat Bias Tee BT-2222
- SKU:
- BT-2222
- MPN:
- BT-2222
- Availability:
- YES
- Weight:
- 0.17 KGS
- Width:
- 10.50 (cm)
- Height:
- 0.55 (cm)
- Depth:
- 0.25 (cm)
Description
KEY SPECIFICATIONS | |
Product Family | Bias Tee |
Band | L-Band |
Input Frequency - Band 1 | L-Band: 950 - 2150 MHz |
RF SPECIFICATIONS | |
Input VSWR | 2.0 : 1 |
Output VSWR | 2.0 : 1 |
ENVIRONMENTAL SPECIFICATIONS | |
Temperature - Operational | -30 to +50˚C |
Temperature - Storage | -40 to +70˚C |
PHYSICAL SPECIFICATIONS | |
Dimensions (L x W x H) | 105 x 55 x 25 mm |
Weight | 170 g |
