Norsat International Inc.

Norsat 4000 Series 4507BF Ku-Band Single-Band LNB

No reviews yet
Product Code: 4507BF
Availability: YES
Weight: 0.20 KGS
Width: 4.30 (cm)
Height: 4.30 (cm)
Depth: 8.50 (cm)
$95.00

Norsat’s Low Noise Blocks (LNBs) provide signal reception for satellite communications around the world. We offer premium performance and reliability in the smallest form factor possible. All of our standard Ku-Band LNBs are backed by a 3 year warranty and nearly forty years of experience as the industry’s leading provider of high performance LNBs. KU-BAND PLL LNB; 12.25-12.75GHZ; LO: +/-500KHZ; NF: 0.7DB; F-CONN



KEY SPECIFICATIONS
Product Family 4000 Series
Band Ku-Band
LO Type PLL
# of onboard LOs Single-band
LO Stability ±500 kHz
Noise Figure 0.7 dB
Input Frequency - Band 1 Ku-Band: 12.25 - 12.75 GHz
Output Frequency 1 L-Band: 950 - 1450 MHz

RF SPECIFICATIONS
LO Frequency 1 11.30 GHz
Phase Noise @ 1KHz offset -70 dBc/Hz
Phase Noise @ 10KHz offset -80 dBc/Hz
Phase Noise @ 100KHz offset -90 dBc/Hz
Conversion Gain 60 dB typ
Input VSWR 2.5 : 1
Output VSWR 2.5 : 1
Output P1dB compression point 2 dBm

ELECTRICAL SPECIFICATIONS
Power Requirements 15 - 24 V
Current Drain 120 mA

INTERFACE SPECIFICATIONS
RF Input Connector WR-75 waveguide grooved
RF Output Connector F-75 Ohm

M & C SPECIFICATIONS
LED Indicators None

ENVIRONMENTAL SPECIFICATIONS
Temperature - Operational -40 to +60°C
Temperature - Storage -40 to +80°C

PHYSICAL SPECIFICATIONS
Dimensions (L x W x H) 85 x 43 x 43 mm
Weight 200 g
