CPI
CPI LKR12S80-12XX Ku-Band Low Noise Amplifier (LNA) 10.70 - 12.75 GHz, 80 K, 50 dB gain, +20 dBm
Product Code:
LKR12S80-12XX
Condition:
New
Availability:
YES
Weight:
10.00 KGS
Request a quote at Contact@orbitalconnect.com or +1.888.315.9545
The LKR12S80-12XX is a CPI Low Noise Amplifier (LNA) for Ku-Band, with 80 K noise temperature, 50 dB gain and +20 dBm rated output power.
LK-12000 series Ku-Band Ultra Low Noise Amplifiers are specifically designed for satellite earth station receiver front ends and other telecommunications applications.
Key advantages
- High reliability HEMT design
- Input/output isolators
- Reverse polarity protection
- Form 'C' alarm
- CE certified, RoHS compliant
Key Specifications
| Band | Ku-Band |
| Input Frequency | Ku-Band: 10.70 - 12.75 GHz |
| Noise Temperature | 80 K |
| Gain | 50 dB minimum |
| Output Power | +20 dBm |
| Power Configuration | +12 to +24 Vdc |
| RF Out Connector | SMA Female |
5 customers are viewing this product
Details
The LKR12S80-12XX is a CPI Low Noise Amplifier (LNA) for Ku-Band, with 80 K noise temperature, 50 dB gain and +20 dBm rated output power.
LK-12000 series Ku-Band Ultra Low Noise Amplifiers are specifically designed for satellite earth station receiver front ends and other telecommunications applications.
Key advantages
- High reliability HEMT design
- Input/output isolators
- Reverse polarity protection
- Form 'C' alarm
- CE certified, RoHS compliant
Key Specifications
| Band | Ku-Band |
| Input Frequency | Ku-Band: 10.70 - 12.75 GHz |
| Noise Temperature | 80 K |
| Gain | 50 dB minimum |
| Output Power | +20 dBm |
| Power Configuration | +12 to +24 Vdc |
| RF Out Connector | SMA Female |
